Vertical slideway for advance and retreat blade up and down. Cutting feed is steady and cutting tools are of long use life. High precision of saw cutting. European design, many groups of tooth gearing, suit to heavy duty cutting, the accuracy is steady...
The cutting scraps are treated together and the maintenance is easy.
|
Model |
FA275 |
FA315 |
FA350 |
FA400 |
|
|
Main motor |
2/4 pole 2/2.4kw |
2/4 pole 2/2.4kw |
2/4 pole 2.4/3kw |
2/4 pole 2.4/3kw |
|
|
Main shaft rotating speed |
96/48 |
88/44 |
48/19 |
38/19 |
|
|
Suitable saw Blade |
OD |
Φ250-300mm |
Φ250-350mm |
Φ250-370mm |
Φ250-400mm |
|
Center Bore |
Φ32mm |
Φ32mm |
Φ32mm |
Φ32mm |
|
|
Pin hole |
2*Φ11*65mmPCD |
2*Φ11*65mmPCD |
2*Φ11*65mmPCD |
2*Φ11*65mmPCD |
|
|
Feeding length |
750mm*many times |
||||
|
Oil pump system |
2.2KW, 4 Pole motor, double –ply pump operating pressure 25-35kg/cm² |
||||
|
Cooling system |
0.09Kw motor, automatic cooling circulation |
||||
|
Compressed air |
0.6-0.9Mpa 160N/min |
|
|||
|
Weight |
1100KGS |
1300KGS |
1400KGS |
1500KGS |
|
|
Size |
2950*1550*2100 |
||||
