Features:
1. Automatic recognition of power in machine and work piece, the processing is both quick and good
2. Slow returning core, boosted by barrow, improving the appearance of the angle.
3. The whole operation is in the computer, simple, quick and correct.
Technical parameters:
|
Specification/Model |
Unit |
EM254A-3SV |
EM384A-3SV |
EM504A-3SV |
EM634A-3SV |
EM754A-3SV |
||
|
Max bending capability |
mm |
Φ25*1.6 |
Φ38*2 |
Φ50*3 |
Φ63*3 |
Φ75*3 |
||
|
Max feeding length |
mm |
2500 |
2500 |
3000 |
3000 |
3000 |
||
|
Bending radius |
Draw bending |
Round Tube |
|
1.5D-4D |
1.5D-5D |
1.5D-5D |
1.5D-5D |
1.5D-3.3D |
|
Rectangular Tube |
|
2.5D-4D |
2D-5D |
2D-5D |
2D-5D |
2.5D-3.3D |
||
|
Roll bending |
Round Tube |
|
6D-∞ |
6D-∞ |
6D-∞ |
6D-∞ |
8D-∞ |
|
|
Rectangular Tube |
|
8D-∞ |
7D-∞ |
7D-∞ |
8D-∞ |
8D-∞ |
||
|
Max bending radius |
mm |
80 |
180 |
250 |
250 |
250 |
||
|
Max bending angle |
degree |
190 |
190 |
190 |
190 |
190 |
||
|
Bending accuracy |
|
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
||
|
Rotary accuracy |
|
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
||
|
Feeding accuracy |
|
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
±0.1ﾟ |
||
|
Machine Size |
mm |
4100*00*1400 |
4910*1200*1600 |
5500*1500*1750 |
5500*1500*1750 |
5600*1600*1850 |
||
|
Weight |
kg |
1500 |
3600 |
4500 |
5500 |
7500 |
||
